RS PRO Pillow Block Unit > UCPX17

Description

Dimension A(mm): 102;
Dimension b (mm): 96;
Dimension h (mm): 101.6;
Dimension H1(mm): 42;
Dimension H2(mm): 202;
Dimension J(mm): 283;
Dimension l (mm): 381;
Dimension N(mm): 27;
Dimension N1(mm): 59;
Dimension S(mm): 39.7;
Shaft diameter (mm):85;
Shape: Pillow Block Unit;
Bearing designation: UCX17;
Nominal size of the mounting bolt: M22;
Unit mass (kg): 17.1;
Bearing housing designation: PX17;
Basic dynamic load rating Cr (kN): 95.5;
Basic dynamic load rating Cor(kN): 71.4;
Compliant with RoHS Directive (corresponding to 10 substances)
