Description
Dimension A(mm): 83;
Dimension b (mm): 65.1;
Dimension h (mm): 76.2;
Dimension H1(mm): 32;
Dimension H2(mm): 151;
Dimension J(mm): 203;
Dimension l (mm): 286;
Dimension N(mm): 25;
Dimension N1(mm): 41;
Dimension S(mm): 25.4;
Shaft diameter (mm):60;
Shape: Pillow Block Unit;
Bearing designation: UCX12;
Nominal size of the mounting bolt: M20;
Unit mass (kg): 7.2;
Bearing housing designation: PX12;
Basic dynamic load rating Cr (kN): 57.5;
Basic dynamic load rating Cor(kN): 40;
Compliant with RoHS Directive (corresponding to 10 substances)
