RS PRO Pillow Block Unit > UCPX11

Description

Dimension A(mm): 79;
Dimension b (mm): 65.1;
Dimension h (mm): 69.8;
Dimension H1(mm): 30;
Dimension H2(mm): 139;
Dimension J(mm): 184;
Dimension l (mm): 260;
Dimension N(mm): 25;
Dimension N1(mm): 36;
Dimension S(mm): 25.4;
Shaft diameter (mm):55;
Shape: Pillow Block Unit;
Bearing designation: UCX11;
Nominal size of the mounting bolt: M20;
Unit mass (kg): 5.53;
Bearing housing designation: PX11;
Basic dynamic load rating Cr (kN): 52.5;
Basic dynamic load rating Cor(kN): 36.1;
Compliant with RoHS Directive (corresponding to 10 substances)
