RS PRO Pillow Block Unit > UCP213

Description

Dimension A(mm): 70;
Dimension A4(mm): 102;
Dimension A5(mm): 118;
Dimension A6(mm): 10;
Dimension A7(mm): 13;
Dimension b (mm): 65.1;
Dimension h (mm): 76.2;
Dimension H1(mm): 27;
Dimension H2(mm): 150;
Dimension H5(mm): 156;
Dimension J(mm): 203;
Dimension l (mm): 265;
Dimension N(mm): 25;
Dimension N1(mm): 29;
Dimension S(mm): 25.4;
Shaft diameter (mm):65;
Shape: Pillow Block Unit;
Material: High carbon chromium bearing steel;
Grease nipple: With grease nipple;
Load type: For light loads;
Without cover;
Bore type: Cylindrical bore with set screw ;
Mass (kg): 5.6;
Basic static load rating (kN): 40;
Basic dynamic load rating (kN): 57.5;
Nominal size of the mounting bolt: M20;
Compliant with RoHS Directive (corresponding to 10 substances)
