RS PRO Pillow Block Unit > UCP207

Description

Dimension A(mm): 48;
Dimension b (mm): 42.9;
Dimension h (mm): 47.6;
Dimension H1(mm): 19;
Dimension H2(mm): 94;
Dimension J(mm): 127;
Dimension l (mm): 167;
Dimension N(mm): 17;
Dimension N1(mm): 21;
Dimension S(mm): 17.5;
Shaft diameter (mm):35;
Shape: Pillow Block Unit;
Material: High carbon chromium bearing steel;
Grease nipple: With grease nipple;
Load type: For light loads;
Without cover;
Bore type: Cylindrical bore with set screw ;
Mass (kg): 1.59;
Basic static load rating (kN): 15.4;
Basic dynamic load rating (kN): 25.9;
Nominal size of the mounting bolt: M14;
Bearing Designation: UC207;
Bearing housing designation: P207;
Compliant with RoHS Directive (corresponding to 10 substances)
