Description
Inner diameter Dc1(mm): 50
Outer diameter Dc (mm): 70
Width Dw(mm): 3
Material: (Main body) High carbon chromium bearing steel
Dimension Ea(mm): 67.4(For reference)
Dimension Eb(mm): 55.5(For reference)
Suitable washer: AS1110
For reference, Mass (g): 23.5
Basic static load rating Coa (N): 143000
Basic dynamic load rating Ca (N): 31500
Suitable inner ring: WS81110
Suitable outer ring: GS81110
Rolling element Material: High carbon chromium bearing steel
Allowable rotational speed (/min) Grease lubrication: 1000
Allowable rotational speed (/min) Oil lubrication: 3900
