Description
Inner diameter d (mm): 120;
Outer diameter D (mm): 180;
Width B (mm): 28;
Chamfer dimension r (mm): 2;
Mass (g): 2070;
Material: (Main body) High carbon chromium bearing steel;
Basic dynamic load rating Cr (N): 85000;
Basic static load rating Cor (N): 79500;
JIS grade: 0;
Shield shape: Contact seal shape on both sides;
Load direction: Radial;
Outer ring type: Flat;
Raceway ring shape: Deep groove ball bearing;
Number of raceway ring rows: Single row;
Rolling element Material: High carbon chromium bearing steel;
Allowable rotational speed (/min) Oil lubrication: 2100;
Bearing series: 6000
