Description
Quantity: 1 piece
Hole shape: Triangle (triangular) 8mm
Part number: 204-0105
Hole shape: Triangle (triangular) 8mm
Tip shape (key): Convex
Material: Zinc alloy
Shape (key): B
Dimension d(mm): 13.5
Finish: Raw
This is a cylinder lock used for swing handle profile cylinder types.
There are two types of locking: normal locking where the key can be removed when locked and unlocked, and clip-in locking where the key can only be removed when locked. (All insert types use clip-in locking)
It comes with a dust-proof shutter (Stainless Steel) to protect the keyhole from dust.
The cylinder lock type has 240 different key variations, and key numbers can be specified. A master key function can also be produced on a made-to-order basis.
The cylinder lock type comes with two keys.
There is also a polyamide plug (with a closed catch) to cover the hole on the handle side when the cylinder is not in use.
