Description
Material: NBR (Nitrile Rubber)
Wire diameter/Tolerance (mm): 5.7 (plus or minus 0.13)
Type: G shape, fixed type
Inner diameter (mm): 159.3
Nominal size: 160
Applications: Oil seals, gaskets, oil-resistant hoses, conveyor belts, printing rolls, spinning top rolls, and other oil-resistant products.
Hardness: 70
Outer diameter (mm): 170.7
Pressure resistance (MPa): 7
Functions: Oil resistance, abrasion resistance, aging resistance
Heat resistance temperature (Celsius degrees): 100
RoHS Directive (10 substances compliance): Compliant
Inner diameter tolerance (mm): 1.26
Excellent oil resistance, abrasion resistance, and aging resistance.
