Description
Material: NBR (Nitrile Rubber)
Wire Diameter/Tolerance (mm): 3.1 (plus or minus 0.10)
Type: G Shape Fixed Use
Inner Diameter (mm): 79.4
Nominal Size: 80
Applications: Oil seals, gaskets, oil-resistant hoses, conveyor belts, printing rolls, spinning top rolls, and other oil-resistant products.
Hardness: 70
Outer Diameter (mm): 85.6
Pressure Resistance (MPa): 7
Functions: Oil resistance, abrasion resistance, aging resistance
Heat Resistance Temperature (Celsius degrees): 100
RoHS Directive (10 substances compliance): Compliant
Inner Diameter Tolerance (mm): 0.69
Excellent oil resistance, abrasion resistance, and aging resistance.
