Description
Material: NBR (Nitrile Rubber)
Wire Diameter/Tolerance (mm): 3.1 (plus or minus 0.10)
Type: G Shape Fixed Type
Inner Diameter (mm): 57.4
Nominal Size: 58
Applications: Oil seals, gaskets, oil-resistant hoses, conveyor belts, printing rolls, spinning top rolls, and other oil-resistant products.
Hardness: 70
Outer Diameter (mm): 63.6
Pressure Resistance (MPa): 7
Functions: Oil resistance, abrasion resistance, aging resistance
Heat Resistance Temperature (Celsius degrees): 100
Compliance with RoHS Directive (10 substances): Yes
Inner Diameter Tolerance (mm): 0.49
Excellent oil resistance, abrasion resistance, and aging resistance.
