Description
Usage: Medical equipment, store fixtures, system kitchens, etc.
Material: Rail / Cold-rolled steel sheet (SPCC), Retainer / Inner side: Hot-dip galvanized steel sheet, Outer side: Polypropylene (PP), Damper part / Polyacetal (POM)
Weight (g): 878
Allowable load (N / pair): 300
Surface finish of rail: Zinc-plated chromate treatment (MFZn-C)
Takigen code 31920
With self-closing mechanism, the drawer is automatically closed from a position 50mm before fully retracted, where the withdrawal force is applied.
The air damper used ensures that the drawer opens smoothly and lightly. Additionally, there is no risk of oil leakage.
For products with a rail length of 400mm or more, the drawer can be extended beyond the rail length.
Simply press the button to easily remove the inner rail.
