Description
Usage: Medical equipment, store fixtures, system kitchens, etc.
Material: Rail/cold-rolled steel plate (SPCC), Retainer/inner side: galvanized steel plate, outer side: polypropylene (PP), damper section: polyacetal (POM)
Weight (g): 466
Permissible load (N/pair): 260
Surface finish rail: zinc plating chromate treatment (MFZn-C)
Takigen code: 31915
The self-closing mechanism applies pulling force from a position 50mm before the drawer is completely stored, automatically closing it.
An air damper is employed, making the drawer light and smooth. There is also no concern about oil leakage.
For products with a rail length of 400mm or more, the drawer can be extended beyond the rail length.
Simply pressing a button allows for easy removal of the inner rail.
