Description
Dimension A (mm): 7.5
Dimension C (mm): 8
Dimension D1 (mm): 12.2
Dimension D2 (mm): 5.5
Dimension H1 (mm): 35
Dimension H2 (mm): 25
Dimension L (mm): 15
Dimension P (mm): 20
Dimension W (mm): 29
Material: (Main body) Steel (SPCC)
Weight (g): 15
Compatible inner diameter (mm): (Set collar) 25
Surface treatment: (Main body) Electroless nickel plating
RoHS Directive (10 substances compliant): Compliant
