Description
Width B (mm): 28;
Outer diameter D (mm): 170;
Inner diameter d (mm): 110;
Chamfer dimension r (mm): 2(minimum);
Shield shape: Double – sided non – contact seal type;
Raceway ring shape: Deep groove ball bearing;
Outer ring type: Flat;
Number of raceway ring rows: Single row;
Material: (Main body) High carbon chromium bearing steel;
Mass (g): 1940;
Coefficient: 15.5;
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 3800;
JIS grade: 0;
Basic rated load Cor (N): 73000;
Basic rated load Cr (N): 85000;
Load direction: Radial;
Rolling element Material: High carbon chromium bearing steel;
Bearing series: 6000
