Description
Inner diameter d (mm): 20
Outer diameter D (mm): 52
Width B (mm): 15
Material: (Main body) High carbon chromium bearing steel
Chamfer dimension r (mm): 1.1
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 14000
Basic dynamic load rating Cr (N): 15900
Basic static load rating Cor (N): 7900
JIS grade: 0
Shield shape: Double-sided non-contact rubber seal type
Load direction: Radial
Outer ring type: Flat
Raceway ring shape: Deep groove ball bearing
Number of raceway ring rows: Single row
Rolling element Material: High carbon chromium bearing steel
Bearing series: 6300
