Description
Contents: 1 set
Travel distance (mm): 650
Part number: ESR4670-26
Specifications
The position where the self & soft-closing mechanism operates is 20 mm before the drawer fully closes for rail lengths up to 350 mm, and 36 mm for rail lengths of 400 mm or more.
The maximum width of the drawer is rail length + 200 mm.
The inner member can be removed by lever operation.
Thanks to the shock-absorbing effect at the outer member mounting section, smooth sliding is achieved even with slight deformation of the cabinet.
