Description
Inner diameter d (mm): 50
Outer diameter D (mm): 110
Width B (mm): 27
Material: (Main body) High carbon chromium bearing steel
Chamfer dimension r (mm): 2
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 6400
Basic dynamic load rating Cr (N): 62000
Basic static load rating Cor (N): 38500
JIS grade: 0
Shield shape: Double-sided non-contact rubber seal type
Load direction: Radial
Outer ring type: Flat
Raceway ring shape: Deep groove ball bearing
Number of raceway ring rows: Single row
Rolling element Material: High carbon chromium bearing steel
Bearing series: 6300
