Description
Inner diameter d (mm): 2
Outer diameter D (mm): 5
Chamfer Dimension r1 (mm): 0.08
Mass (g): 0.17
Material: (Main body)SUS440C
Width B1 (mm): 2.3
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 85000
Compliant with RoHS Directive (corresponding to 10 substances)
Basic dynamic load rating Cr (N): 169
Basic static load rating Cor (N): 50
JIS grade: 0
Shield shape: Double-sided steel plate shield type
Load direction: Radial
Outer ring type: Flat
Raceway ring shape: Deep groove ball bearing
Number of raceway ring rows: Single row
Rolling element Material:SUS440C
Bearing series: 600
