Description
Content Volume: 1 piece
Screw Dimension: M4*0.7-12L
Type Finish: Surface
Part Number: MBSC04C
Screw Dimension: M4*0.7-12L
TRUSCO Part No.297-5424
Stroke (mm): 0.4
Width (mm): 12.7
Weight (g): 7
Type Finish: Surface
Depth (mm): 12.7
Dimension H (mm): –
Dimension A (mm): –
Dimension F (mm): –
Dimension D (mm): –
Dimension E (mm): –
Dimension B (mm): –
Dimension C (mm): –
Dimension G (mm): –
Clamping Force (kN): 1.7
Allowable Tightening Torque (N*m): 5.6
When unclamped, the clamping tip rises with the O-ring.
