Description
Inner diameter d (mm): 12
Outer diameter D (mm): 32
Width B (mm): 10
Chamfer dimension r (mm): 0.6(minimum)
Mass (g): 37
Material: (Main body) High carbon chromium bearing steel
Basic dynamic load rating Cr (N): 6100
Basic static load rating Cor (N): 2750
JIS grade: 0
Shield shape: One-sided contact seal type
Load direction: Radial
Outer ring type: Flat
Raceway ring shape: Deep groove ball bearing
Number of raceway ring rows: Single row
Rolling element Material: High carbon chromium bearing steel
Bearing series: 6200
