Description
Inner diameter d (mm): 3
Outer diameter D (mm): 10
Width B1 (mm): 4
Material: (Main body) High carbon chromium bearing steel
Mass (g): 1.66
Chamfer dimension r (mm): –
Chamfer dimension r1 (mm): (minimum): 0.15
Designation: 623
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 50000
JIS grade: 0
Basic rated load Cor (N): 218
Basic rated load Cr (N): 630
Shield shape: Double – sided shielded type
Load direction: Radial
Outer ring type: Flat
Raceway ring shape: Deep groove ball bearing
Number of raceway ring rows: Single row
Rolling element Material: High carbon chromium bearing steel
Bearing series: 6200
