Description
Inner diameter d (mm): 45;
Outer diameter D (mm): 100;
Width B (mm): 25;
Material: (Main body) High carbon chromium bearing steel;
Mass (g): 829;
Chamfer dimension r (mm): 1.5(minimum);
Coefficient: 13.1;
Allowable rotational speed (/min [r.p.m]) Grease lubrication: 4800;
JIS grade: 0;
Basic rated load Cor (N): 32000;
Basic rated load Cr (N): 53000;
Shield shape: Contact seal shape on both sides;
Load direction: Radial;
Outer ring type: Flat;
Raceway ring shape: Deep groove ball bearing;
Number of raceway ring rows: Single row;
Rolling element Material: High carbon chromium bearing steel;
Bearing series: 6300
