Description
Content Quantity: 1 unit
Dimensions (Width * Height * Depth) (mm): 400 * 600 * 200
Outer Dimensions (Width * Height * Depth) (mm): –
Model Number: OP20-46CA
Specifications: With roof, Transparent door, Low formaldehyde, Machining hole processing
Material: Body and Roof: ABS resin
Weight (kg): 5.7
Type: General-Purpose type
Standard: CA (CA200, CA-G04)
Total Height (mm): 621
Protection Rating: IP44
Effective Depth (mm): 166
Installation Location: For outdoor use
Material (Door): Acrylic resin
Color (Door): Light smoke color
Color (Roof): White gray color (5YR8.5/0.5)
Board Dimensions (Height * Width) (mm): 490 * 320
RoHS Directive (Compliant with 10 substances): Compliant
Door Type: Single door
Mounting Board: Wooden board (15mm)
Outer Dimensions (Width * Height * Depth) (mm): –
Outer Dimension Height (mm): 621
Color (Body): White gray color (5YR8.5/0.5)
Dimensions (Width * Height * Depth) (mm): 400 * 600 * 200
Box Plate Thickness (mm): Door and Body: 1.8 to 3.5
Effective Depth of Handle Part (mm): –
