Description
Capacity: 1 unit
Dimensions (Width * Height * Depth) (mm): 600 * 500 * 200
External Dimensions (Width * Height * Depth) (mm): –
Model Number: OP20-65A
Specifications: With roof, low formaldehyde, machining hole processing
Material: Body Roof: ABS resin
Weight (kg): 6.9
Type: General-Purpose Type
Standard: CA (CA200, CA-G04)
Overall Height (mm): 521
Protection Level: IP44
Effective Depth (mm): 165
Installation Location: Outdoor use
Material (Door): ABS resin
Color (Door): White-gray color (5YR8.5/0.5)
Color (Roof): White-gray color (5YR8.5/0.5)
Board Dimensions (Height * Width) (mm): 390 * 520
RoHS Directive (10 Substances Compliance): Compliant
Door Type: Single Door
Mounting Board: Wooden board (15mm)
External Dimensions (Width * Height * Depth) (mm): –
External Dimensions Height (mm): 521
Color (Body): White-gray color (5YR8.5/0.5)
Dimensions (Width * Height * Depth) (mm): 600 * 500 * 200
Box Plate Thickness (mm): Door: 1.8闂?, Body: 1.8闂?.5
Effective Depth of Handle Section (mm): –
