Description
Usage: For supporting the roll;
Material: Bearing: High carbon chromium steel, ;
Bearing housing: Grey cast iron;
Shaft diameter (mm):40;
Shape: Pillow shape;
Mass (kg): 2.14;
Dimension l (mm): 184;
Dimension h (mm): 49.2;
Basic static load rating (kN): 19.8;
Basic dynamic load rating (kN): 32.6;
Nominal size of the mounting bolt: M14;
Dimension A(mm): 54;
Dimension S(mm): 19;
Dimension b (mm): 49.2;
Dimension N(mm): 17;
Dimension J(mm): 137;
Dimension H1(mm): 18;
Dimension H2(mm): 98;
Dimension N1(mm): 21
