Description
Contents: 1 unit
Dimensions (Width * Height * Depth) (mm): 200 * 200 * 100
External Dimensions (Width * Height * Depth) (mm): –
Model Number: OP10-22A
Specifications: With roof, low formaldehyde, machining hole processing
Material: Body Roof: ABS resin
Weight (kg): 0.57
Type: General-Purpose Type
Standard: CA (CA200, CA-G04)
Overall Height (mm): 211
Protection Class: IP44
Effective Depth (mm): 67
Installation Location: Outdoor use
Material (Door): ABS resin
Color (Door): White gray (5YR8.5/0.5)
Color (Roof): White gray (5YR8.5/0.5)
Board Dimensions (Height * Width) (mm): 120 * 140
RoHS Directive (10 substances compliant): Compliant
Door Type: Single Door
Mounting Board: Wooden board (9mm)
External Dimensions (Width * Height * Depth) (mm): –
External Dimensions Height (mm): 211
Color (Body): White gray (5YR8.5/0.5)
Dimensions (Width * Height * Depth) (mm): 200 * 200 * 100
Box Plate Thickness (mm): Door: 1.8闂?, Body: 1.8闂?.5
Handle Effective Depth (mm): –
