Description
Inner diameter d (mm): 22;
Outer diameter D (mm): 44;
Width B (mm): 12;
Chamfer dimension r (mm): 0.6;
Mass (g): 74;
Material: (Main body) High carbon chromium bearing steel;
Compliant with RoHS Directive (corresponding to 10 substances);
Basic dynamic load rating Cr (N): 9400;
Basic static load rating Cor (N): 5050;
JIS grade: 0;
Shield shape: Open type;
Load direction: Radial;
Outer ring type: Flat;
Raceway ring shape: Deep groove ball bearing;
Number of raceway ring rows: Single row;
Rolling element Material: High carbon chromium bearing steel;
Allowable rotational speed (/min) Grease lubrication: 17000;
Allowable rotational speed (/min) Oil lubrication: 20000
