Description
Quantity: 1 piece
Dimension L2 (mm): 45
Dimension L1 (mm): 50
Part Number: BP-19-1-1-B-Ivory
Dimension L1 (mm): 50
Dimension L2 (mm): 45
Dimension L3 (mm): –
Dimension W (mm): 80
Dimension H (mm): 15.5
Dimension t (mm): 7.5
Dimension W1 (mm): –
Dimension W2 (mm): –
Dimension W3 (mm): –
Dimension P1 (mm): 30
Dimension P2 (mm): 50
Dimension P3 (mm): –
Dimension P4 (mm): –
N-
Dimension M: M5
Usage: Hatch canopy for boats
Compatibility: For pot bind screws
Color: Ivory
Weight (g): 34
Material (shaft): Stainless Steel (SUS304)
Standard color: Ivory
Material (blade): Polyamide (PA)
Takigen Code: 12306
Since there are few protrusions on the surface, it is safe to use on the floor.
