Quantity: 1 piece
External Dimensions D(mm): 130
Material (Cover): ABS Resin UL94HB
Material (Body): ABS Resin (UL94HB)
Part Number: SW-130S
Type: S Type
Operating Temperature Range (Celsius degrees): -10 to 60
External Dimensions D(mm): 130
External Dimensions W(mm): 40
External Dimensions H(mm): 25
Finish: Full Texture Finish
Material (Cover): ABS Resin UL94HB
Flame Resistance: –
Material (Body): ABS Resin (UL94HB)
Dimension R1(mm): –
Dimension R2(mm): –
Dimension t1(mm): –
Dimension t2(mm): –
Dimension t3(mm): –
Color (Cover): Light Gray
Compatible Body Color: Light Gray
RoHS Directive (10 Substances Compliance): Compliant
Characteristics: General-Purpose type
Weight (g): 43
Effective Dimension (Width) (mm): 32.8 (Internal)
Effective Dimension (Depth) (mm): 122.8 (Internal)
Effective Dimension (Height) (mm): 17 (Internal)
One-Touch Open-Close Structure.
Internal Space is Wide and Usable.
Compact Case and Versatile Type.
