Description
Upper belt width (mm): 10;
Belt height (mm): 5.5;
Effective pitch circumference (inch): 66;
Type: M type;
Material: Rubber;
Type: Standard;
Category: V-belt;
Operating temperature range (Celsius degrees): -40 to +70;
Angle (degrees): 40;
Electrical resistance value: 50 megohm resistor or above;
In accordance with JIS standard K6323 ;
Material: (belt)Rubber;
Effective outer circumference (mm): 1676;
Maximum speed (m/sec): 30;
Minimum pulley diameter (mm): 150;
Compliant with RoHS Directive (corresponding to 10 substances);
Belt type: M
