Description
Description: Quantity: 1 piece
Outer dimensions D(mm): 85
Material (cover): Flame retardant: ABS resin
Material (body): Flame retardant: ABS resin
Part number: SW-N85G
Type: G type
Operating temperature range (Celsius degrees): -10 to 60
Outer dimensions D(mm): 85
Outer dimensions W(mm): 60
Outer dimensions H(mm): 40
Finish: Overall textured finish
Material (cover): Flame retardant: ABS resin
Flame retardant: UL94V-0 main component
Material (body): Flame retardant: ABS resin
Dimension R1(mm): –
Dimension R2(mm): –
Dimension t1(mm): –
Dimension t2(mm): –
Dimension t3(mm): –
Color (cover): Gray
Compatible body color: Gray
RoHS directive (10 substances compliance): Compliant
Characteristics: Flame retardant type
Weight (g): 50
Effective dimension (width)(mm): 52.8 (internal)
Effective dimension (depth)(mm): 77.8 (internal)
Effective dimension (height)(mm): 32.7 (internal)
One-touch Open-Close structure.
Internal space is wide and usable.
Compact case with multi-purpose type.
