Description
Description
Quantity: 1 piece
Notch Count: 2
Contact Configuration: 2a
Notch Angle (degrees): 90
Part Number: AR22PR-220R
Protection Structure: Operating Part: IP65 (Oil-resistant Type)
Contact Configuration: 2a
Frame: Round Frame
Notch Angle (degrees): 90
Notch Count: 2
Mounting Dimensions (mm): Diameter 22.3 / Diameter 25.5 Common
Mounting Hole Diameter (mm): 22
Rated Operating Current (A): AC-15 (Coil Load): 24V/6A, 110V/6A, 220V/6A, 440V/2.5A; DC-13 (Coil Load): 24V/4A, 110V/1.3A, 220V/0.45A; DC-12 (Resistive Load): 24V/6A, 110V/2.5A, 220V/1A
Return Mechanism: Manual
Operation Part Shape: Knob Type
Mechanical Durability: Over 1 million cycles
Type: Standard Type
Category: Selector
Dielectric Strength: Charging Part to Ground: AC2500V for 1 minute; Between Disparate Charging Parts: AC2500V for 1 minute
Rated Insulation Voltage (V): AC/DC600
Rated Frequency (Hz): 50/60
Terminal Screws: M3.5 with flat washer, both positive and negative types (Self-up type)
Storage Temperature (Celsius degrees): -40 to 80
Insulation Resistance (Megaohms): Charging Part to Ground, Between Disparate Charging Parts: 100 or more (measured with DC500V Megohmmeter)
Ambient Operating Temperature (Celsius degrees): -20 to 70 (No freezing or condensation)
Electrical Durability: Over 500,000 cycles (at AC220V/6A); Over 1,000,000 cycles (at AC220V/3A)
Short Circuit Protection Device: Fuse 15A
Rated Impulse Voltage (kV): 6
Contamination Level (Operating Environment): 3
Vibration Resistance Test: Multi-amplitude 0.1mm, Frequency 10-55Hz; Vibration Endurance Test: Multi-amplitude 3.0mm, Frequency 16.7Hz
Rated Operating Current (A): 10
Operating Frequency (cycles/hour): 1200 (at 40% utilization)
Material (Ring): –
Knob Color: Red
Conditional Short Circuit Current (A): 1000
Relative Humidity (%RH): Inside Panel: 45 to 85 (at -5 to 40 Celsius degrees; no freezing or condensation)
Impact Resistance (Malfunction): 100 m/s2
Impact Resistance (Endurance): 500 m/s2
Special Handling Item: –
Front Clamp Structure
Contact Transformer Unit Addition and Replacement: One-touch
Two-Direction Wiring for Improved Work Efficiency
