Description
Description
Quantity: 1 piece
Number of notches: 2
Contact configuration: 2a
Notch angle (degrees): 90
Part number: AR22PR-220G
Protection structure: Operating part: IP65 (Oil-resistant)
Contact configuration: 2a
Frame: Round frame
Notch angle (degrees): 90
Number of notches: 2
Mounting dimensions (mm): Diameter 22.3, Diameter 25.5 compatible
Mounting hole diameter (Diameter mm): 22
Rated operating current (A): AC-15 (Coil load): 24V/6, 110V/6, 220V/6, 440V/2.5 DC-13 (Coil load): 24V/4, 110V/1.3, 220V/0.45 DC-12 (Resistive load): 24V/6, 110V/2.5, 220V/1
Reset method: Manual
Operating part shape: Knob type
Mechanical durability: Over 1 million operations
Type: Standard type
Category: Selector
Dielectric strength: Between charged part and ground, between different polar charged parts: AC2500V for 1 minute
Rated insulation voltage (V): AC/DC600
Rated frequency (Hz): 50/60
Terminal screw: M3.5 plus/minus screw with square washer (Self-up type)
Storage temperature (Celsius degrees): -40 to 80
Insulation resistance (Megaohm): Between charged part and ground, between different polar charged parts: 100 or more (measured with DC500V megger)
Operating ambient temperature (Celsius degrees): -20 to 70 (no freezing or condensation)
Electrical durability: Over 500,000 operations (at AC220V 6A): Over 1 million operations (at AC220V 3A)
Short-circuit protection device: Fuse 15A
Rated impulse withstand voltage (kV): 6
Pollution degree (usage environment): 3
Vibration resonance test: Complex amplitude 0.1mm, Frequency: 10闂?5Hz, Steady vibration durability test: Complex amplitude 3.0mm, Frequency: 16.7Hz
Rated continuous current (A): 10
Switching frequency (cycles/hour): 1200 (usage rate 40%)
Material (ring): –
Color (knob): Green
Conditional short-circuit current (A): 1000
Relative humidity (%RH): Inside panel: 45闂?5 (-5 to 40 Celsius degrees) (no freezing or condensation)
Shock resistance (malfunction) (m/s2): 100
Shock resistance (durability) (m/s2): 500
Special Handling Item: –
Front Clamp Structure
Contact Transformer Unit Addition and Replacement: One-touch
Two-Direction Wiring for Improved Work Efficiency
