Description
Description
Quantity: 1 piece
Number of notches: 2
Contact configuration: 1a
Notch angle (degrees): 90
Part number: AR22PR-210BZ0
Protection structure: Operating part: IP65 (oil-proof type)
Contact configuration: 1a
Frame: Round frame
Notch angle (degrees): 90
Number of notches: 2
Mounting dimensions (mm): Diameter 22.3, Diameter 25.5 compatible
Mounting hole diameter (Diameter mm): 22
Rated operating current (A): AC-15 (Coil load): 24V/6, 110V/6, 220V/6, 440V/2.5; DC-13 (Coil load): 24V/4, 110V/1.3, 220V/0.45; DC-12 (Resistive load): 24V/6, 110V/2.5, 220V/1
Return method: Manual
Operating part shape: Knob type
Mechanical durability: Over 1 million cycles
Type: Standard type
Kind: Selector
Withstand voltage: Between charged parts and earth / Between opposite charged parts: AC2500V for 1 minute
Rated insulation voltage (V): AC/DC 600
Rated frequency (Hz): 50/60
Terminal screws: Square washer attached M3.5 screws compatible with both plus and minus (self-up type)
Storage temperature (Celsius degrees): -40 to 80
Insulation resistance (Megaohm): Between charged parts and earth / Between opposite charged parts: 100 or more (measured with DC 500V megohmmeter)
Operating ambient temperature (Celsius degrees): -20 to 70 (provided there is no freezing or condensation)
Electrical durability: Over 500,000 cycles (at AC220V 6A); Over 1 million cycles (at AC220V 3A)
Short-circuit protection device: Fuse 15A
Rated impulse withstand voltage (kV): 6
Pollution degree (operating environment): 3
Vibration resonance test: Double amplitude 0.1mm, Frequency: 10闂?5Hz; Steady vibration endurance test: Double amplitude 3.0mm, Frequency: 16.7Hz
Rated current carrying capacity (A): 10
Operating frequency (cycles/hour): 1200 (duty cycle 40%)
Material (ring): –
Color (knob): Black
Conditional short-circuit current (A): 1000
Relative humidity (%RH): Inside panel: 45闂?5 (at -5 to 40 Celsius degrees) (provided there is no freezing or condensation)
Shock resistance (malfunction) (m/s2): 100
Shock resistance (durability) (m/s2): 500
Special response product: Water-soluble cutting oil, tropical treatment product
Pre-tightening structure
Contact: Addition and replacement of transformer unit is one-touch
Improved work efficiency with 2-direction wiring
