Quantity: 1 piece
External Dimension D (mm): 50
Material (Cover): ABS Resin UL94HB
Material (Body): ABS Resin (UL94HB)
Part Number: SW-50B
Trusco Part Number: 375-3590
Type: Type B
Operating Temperature Range (Celsius degrees): -10 to 60
External Dimension D (mm): 50
External Dimension W (mm): 35
External Dimension H (mm): 25
Finish: Full grain finish
Material (Cover): ABS Resin UL94HB
Flame Retardant: –
Material (Body): ABS Resin (UL94HB)
Dimension R1 (mm): –
Dimension R2 (mm): –
Dimension t1 (mm): –
Dimension t2 (mm): –
Dimension t3 (mm): –
Color (Cover): Black
Compatible Body Color: Black
RoHS Directive (10 substances compliance): Compliant
Characteristics: General-Purpose type
Self Weight (g): 14
Effective Dimension (Width) (mm): 27.8 (internal)
Effective Dimension (Depth) (mm): 42.8 (internal)
Effective Dimension (Height) (mm): 17.7 (internal)
One-touch Open-Close structure.
Internal space is wide and usable.
Compact case with multi-purpose type.
