Description
Inner diameter d (mm): 170;
Outer diameter D (mm): 310;
Width B (mm): 52;
Mass (g): 14500;
Material: (Main body) High carbon chromium bearing steel;
Basic dynamic load rating Cr (N): 212000;
Basic static load rating Cor (N): 223000;
JIS grade: 0;
Shield shape: Open type;
Load direction: Radial;
Outer ring type: Flat;
Raceway ring shape: Deep groove ball bearing;
Number of raceway ring rows: Single row;
Rolling element Material: High carbon chromium bearing steel;
Allowable rotational speed (/min) Grease lubrication: 2000;
Allowable rotational speed (/min) Oil lubrication: 2400;
Bearing series: 6200
