Description
Description: Quantity: 1 piece
Operation method: Non-reversible
Presence of case: Without Case Cover
Coil rated voltage (V): AC240
Part number: SC-0 Coil AC240V 1A
Rated continuous current (A): 20
Rated operating voltage (V): AC200
Auxiliary contacts: 1a
Frame: Type 0
Coil rated voltage (V): AC240
Release voltage (V): 50Hz: 70-98, 60Hz: 80-110
International standards: IEC, EN, VDE, BS, UL, CSA certified
Type: SC-0
Compatible thermal relay: TR-0N
Compatible rail width (mm): 35
Electrical durability: 2 million times (AC-3), 30,000 times (AC-4), 500,000 times (AC-1)
Mechanical durability: 10 million times
Electromagnet capacity (VA)/when energized 100V 50Hz: 90/100-110V 60Hz: 95
Electromagnet capacity (VA)/when saved 200V 50Hz: 9, 200-220V 60Hz: 9
Operating time (ms): (Coil ON 闂?Main contact ON) 9-20, (Coil OFF 闂?Main contact OFF): 5-16
Closed circuit voltage (V): 50Hz: 53-63, 60Hz: 58-68
Accessories: Includes 2 heat element thermal relay
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection structure: Without Case Cover
Contact configuration: [Auxiliary] Double contacts
Rated insulation voltage (V): 690
Operation method: Non-reversible
Rated frequency (Hz): 50/60
Reset method: Manual
Mounting screw: 2-M4
Rated impulse withstand voltage (kV): 6
Loss (W): 200V 50Hz: 2.7, 200-220V: 2.8
Coil Voltage (V): AC240
Switching frequency (times/hour): 1800 (AC-3), 600 (AC-4)
Presence of case: Without Case Cover
Rated capacity (kW) three-phase squirrel-cage motor (AC-3): (200-240V) 2.7, (380-440V) 4
Rated capacity (kW) single-phase motor (AC-3): 0.5 (100-120)
Rated capacity (kW) inching plugging (AC-4): (200-240): 2.2, (380-440): 4
Rated operating current (A) three-phase squirrel-cage motor (AC-3): (200-240V) 13, (380-440V) 9
