Description
Operation Method: Non-reversible Type
Case: Without Case Cover
Coil Rated Voltage (V): AC110
Part Number: SC-0 Coil AC110V 1B
Rated Energizing Current (A): 20
Rated Operating Voltage (V): AC200
Auxiliary Contact: 1b
Frame: Type 0
Open Circuit Voltage (V): 50Hz: 35闂?9, 60Hz: 40闂?5
International Standards: IEC, EN, VDE, BS, UL, CSA Certified
Model: SC-0
Compatible Thermal Relay: TR-0N
Compatible Rail Width (mm): 35
Electrical Durability: 2,000,000 times (AC-3), 30,000 times (AC-4), 500,000 times (AC-1)
Mechanical Durability: 10,000,000 times
Electromagnet Capacity (VA) / At Power ON: 100V 50Hz: 90 / 100-110V 60Hz: 95
Electromagnet Capacity (VA) / At Holding: 100V 50Hz: 9, 100-110V 60Hz: 9
Operating Time (ms): (Coil ON 闂?Main Contact ON) 9闂?0, (Coil OFF 闂?Main Contact OFF) 5闂?6
Closed Circuit Voltage (V): 50Hz: 53闂?3, 60Hz: 58闂?8
Accessories: With 2 Heat Element Thermal Relays
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Mass (kg): 0.32
Type: Electromagnetic Contactor
Protection Structure: Without Case Cover
Contact Configuration: [Auxiliary] Double Contact
Rated Insulation Voltage (V): 690
Operating Frequency (Hz): 50/60
Reset Method: Manual
Mounting Screws: 2-M4
Rated Impulse Withstand Voltage (kV): 6
Loss (W): 100V 50Hz: 2.7, 100-110V: 2.8
Coil Voltage (V): AC110
Switching Frequency (Operations per Hour): 1800 (AC-3), 600 (AC-4)
Rated Capacity (kW) Three-phase Cage Motor (AC-3): (200-240V) 2.7, (380-440V) 4
Rated Capacity (kW) Single-phase Motor (AC-3): 0.5 (100-120V)
Rated Capacity (kW) Inching Plugging (AC-4): (200-240V) 2.2, (380-440V) 4
Rated Operating Current (A) Three-phase Cage Motor (AC-3): (200-240V) 13, (380-440V) 9
Rated Operating Current (A) Single-phase Motor (AC-3): (100V) 13, (220V) 13
