Description
Description
Quantity: 1 piece
Operation Mode: Non-reversible
Case Cover: Without Case Cover
Coil Rated Voltage (V): AC415
Part Number: SC-03 Coil AC415V 1A
Rated Continuous Current (A): 20
Rated Operating Voltage (V): AC200
Auxiliary Contact: 1a
Frame: Type 03
Coil Rated Voltage (V): AC415
Open Voltage (V): 50Hz: 70闂?8, 60Hz: 80闂?10
Standards and Certifications: IEC, EN, VDE, BS, UL, CSA Certified
Model: SC-03
Compatible Thermal Relay: TR-0N
Rail Width (mm): 35
Electrical Durability: 2 million cycles (AC-3), 30,000 cycles (AC-4), 500,000 cycles (AC-1)
Mechanical Durability: 10 million cycles
Electromagnet Capacity (VA) / Inrush at 200V 50Hz: 90 / 200-220V 60Hz: 95
Electromagnet Capacity (VA) / Holding at 200V 50Hz: 9, 200-220V 60Hz: 9
Operation Time (ms): (Coil ON 闂?Main contacts ON): 9闂?0, (Coil OFF 闂?Main contacts OFF): 5闂?6
Closed Circuit Voltage (V): 50Hz: 53闂?3, 60Hz: 58闂?8
Accessories: Comes with 2 Heat Element Thermal Relay
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection Structure: Without Case Cover
Contact Configuration: [Auxiliary] Double Contact
Rated Insulation Voltage (V): 690
Operation Mode: Non-reversible
Rated Frequency (Hz): 50/60
Reset Method: Manual
Mounting Screw: 2-M4
Rated Impulse Voltage (kV): 6
Power Loss (W): 200V 50Hz: 2.7, 200-220V: 2.8
Coil Voltage (V): AC415
Switching Frequency (cycles/hour): 1800 (AC-3), 600 (AC-4)
Case Cover: Without Case Cover
Rated Capacity (kW) Three-phase Cage Motor (AC-3): (200-240V) 2.2, (380-440V) 2.7
Rated Capacity (kW) Single-phase Motor (AC-3): 0.4 (100-120V)
Rated Capacity (kW) Inching Plugging (AC-4): (200-240V): 1.5, (380-440V): 2.2
