Description
Description: Quantity: 1 piece
Operating method: Reversible (with perfect lock)
Case presence: Without Case Cover
Coil rated voltage (V): AC200
Product number: SC-03RM/V Coil AC200V
Rated continuous current (A): 20
Rated operating voltage (V): AC200
Auxiliary contacts: –
Frame: Type 03
Coil rated voltage (V): AC200
Release voltage (V): 50Hz: 70-98, 60Hz: 80-110
International standards: IEC, EN, VDE, BS, UL, CSA certified
Model: SC-03RM
Compatible thermal relay: TR-0N
Compatible rail width (mm): 35
Electrical durability: 2 million times (AC-3), 30,000 times (AC-4), 500,000 times (AC-1)
Mechanical durability: 10 million times
Electromagnet capacity (VA)/when energized 200V 50Hz: 90/200-220V 60Hz: 95
Electromagnet capacity (VA)/when stored 200V 50Hz: 9, 200-220V 60Hz: 9
Operating time (ms): (Coil ON 闂?main contact ON) 9-20, (Coil OFF 闂?main contact OFF): 5-16
Closed circuit voltage (V): 50Hz: 53-63, 60Hz: 58-68
Accessories: 2 heat element thermal relay included
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection structure: Without Case Cover
Contact configuration: [Auxiliary] Double contacts
Rated insulation voltage (V): 690
Operating method: Reversible (with perfect lock)
Rated frequency (Hz): 50/60
Reset method: Manual
Mounting screw: 2-M4
Rated impulse withstand voltage (kV): 6
Loss (W): 200V 50Hz: 2.7, 200-220V: 2.8
Coil Voltage (V): AC200
Switching frequency (times/hour): 1800 (AC-3), 600 (AC-4)
Case presence: Without Case Cover
Rated capacity (kW) three-phase squirrel cage motor (AC-3): (200-240V) 2.2, (380-440V) 2.7
Rated capacity (kW) single-phase motor (AC-3): 0.4 (100-120)
Rated capacity (kW) inching plugging (AC-4): (200-240): 1.5, (380-440): 2.2
Rated operating current (A) three-phase squirrel cage motor (AC-3): (200-240V) 11, (380-440V) 7
Rated operating current (A) single-phase motor (AC-3): (100V) 11, (200V) 11
Rated operating current (A) inching plugging (AC-4): (200-240V): 8, (380-440V) 6
Rated operating current (A) resistive load (AC-1): (200-240V) 20, (380-440V) 20
Operation method: Mechanical latch type (AC Operated Type)
Terminal cover: None
Breaking current (A): three-phase squirrel cage motor (AC-3): 110 (220V), 90 (440V)
Closed circuit current (A): three-phase squirrel cage motor (AC-3): 132 (220V), 108 (440V)
Global standard product compliant with international standards (IEC standards).
Auxiliary contacts are equipped with high contact reliability double contacts as standard.
