Description
Quantity: 1 piece
Operating Method: Reversible (with Perfect Lock)
Case Presence: Without Case Cover
Coil Rated Voltage (V): AC200
Model Number: SC-03RM/T Coil AC200V 1B * 2
Rated Continuous Current (A): 20
Rated Operating Voltage (V): AC200
Auxiliary Contacts: 1b * 2
Frame: 03 Type
Coil Rated Voltage (V): AC200
Release Voltage (V): 50Hz: 70-98, 60Hz: 80-110
Standards International Standards: IEC, EN, VDE, BS, UL, CSA Certified
Type: SC-03RM
Compatible Thermal Relay: TR-0N
Compatible Rail Width (mm): 35
Electrical Durability: 2 million times (AC-3), 30 thousand times (AC-4), 500 thousand times (AC-1)
Mechanical Durability: 10 million times
Electromagnet Capacity (VA) / During Operation 200V 50Hz: 90 / 200-220V 60Hz: 95
Electromagnet Capacity (VA) / During Storage 200V 50Hz: 9, 200-220V 60Hz: 9
Operating Time (ms): (Coil ON 闂?Main Contact ON) 9-20, (Coil OFF 闂?Main Contact OFF): 5-16
Closed Circuit Voltage (V): 50Hz: 53-63, 60Hz: 58-68
Accessories: 2 Heat Element Thermal Relay Included
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection Structure: Without Case Cover
Contact Configuration: [Auxiliary] Double Contact
Rated Insulation Voltage (V): 690
Operating Method: Reversible (with Perfect Lock)
Rated Frequency (Hz): 50/60
Reset Method: Manual
Mounting Screw: 2-M4
Rated Impulse Withstand Voltage (kV): 6
Loss (W): 200V 50Hz: 2.7, 200-220V: 2.8
Coil Voltage (V): AC200
Switching Frequency (times/hour): 1800 (AC-3), 600 (AC-4)
Case Presence: Without Case Cover
Rated Capacity (kW) Three-Phase Squirrel-Cage Motor (AC-3): (200-240V) 2.2, (380-440V) 2.7
Rated Capacity (kW) Single-Phase Motor (AC-3): 0.4 (100-120)
Rated Capacity (kW) Inch/Plugging (AC-4): (200-240): 1.5, (380-440): 2.2
