Description
Description
Quantity: 1 piece
Operating Method: Non-Reversible
Presence of Case: Without Case Cover
Coil Rated Voltage (V): AC115
Part Number: SC-03 Coil AC115V 1A
Rated Continuous Current (A): 20
Rated Operating Voltage (V): AC200
Auxiliary Contact: 1a
Frame: Type 03
Coil Rated Voltage (V): AC115
Open Voltage (V): 50Hz: 35-49, 60Hz: 40-55
International Standards: IEC, EN, VDE, BS, UL, CSA Certified
Model: SC-03
Compatible Thermal Relay: TR-0N
Compatible Rail Width (mm): 35
Electrical Durability: 2 million times (AC-3), 30,000 times (AC-4), 500,000 times (AC-1)
Mechanical Durability: 10 million times
Electromagnet Capacity (VA) / During Operation 100V 50Hz: 90 / 100-110V 60Hz: 95
Electromagnet Capacity (VA) / During Storage 100V 50Hz: 9, 100-110V 60Hz: 9
Operating Time (ms): (Coil ON 闂?Main Contact ON) 9-20, (Coil OFF 闂?Main Contact OFF): 5-16
Closed Circuit Voltage (V): 50Hz: 53-63, 60Hz: 58-68
Accessories: Includes 2 Heat Element Thermal Relay
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection Structure: Without Case Cover
Contact Configuration: [Auxiliary] Double Contact
Rated Insulation Voltage (V): 690
Operating Method: Non-Reversible
Rated Frequency (Hz): 50/60
Reset Method: Manual
Mounting Screw: 2-M4
Rated Impulse Withstand Voltage (kV): 6
Loss (W): 100V 50Hz: 2.7, 100-110V: 2.8
Coil Voltage (V): AC115
Operating Frequency (times/hour): 1800 (AC-3), 600 (AC-4)
Presence of Case: Without Case Cover
Rated Capacity (kW) Three-Phase Squirrel Cage Motor (AC-3): (200-240V) 2.2, (380-440V) 2.7
Rated Capacity (kW) Single-Phase Motor (AC-3): 0.4 (100-120)
Rated Capacity (kW) inching plugging (AC-4): (200-240): 1.5, (380-440): 2.2
