NSK (Nippon Seiko Kabushiki Kaisha) Pillow Block Unit, Oil – free type >UCP216

¥18,902

SKU: r22058564ecec Category:

Description

Contents: 1 piece
Axis diameter (mm): 80
Basic dynamic rated load (kN): 72.5

Dimension A (mm): 78
Dimension B (mm): 82.6
Dimension H (mm): 88.9
Dimension H1 (mm): 30
Dimension H2 (mm): 175
Dimension J (mm): 232
Dimension L (mm): 292
Dimension L1 (mm): 85
Dimension N (mm): 25
Dimension N1 (mm): 28
Dimension S (mm): 33.3
Axis diameter (mm): 80
Shape: Pillow block unit
Grease nipple: No grease nipple
Load type: For light load
Cover: No cover
Axis hole type: Cylindrical hole type (with set screw)
Mass (kg): 9
Basic static rated load (kN): 53
Basic dynamic rated load (kN): 72.5
Bearing call number: UC216D1
Mounting bolt specification: M20
Bearing box call number: P216

This is a representative type of bearing unit, equivalent to the combination of the traditional widely used plummer block and self-aligning bearings. It can be easily mounted onto the shaft by simply tightening the set screw with a ball, and is most commonly used in transmission devices and general machinery.
