NSK (Nippon Seiko Kabushiki Kaisha) Pillow Block Unit, Oil – free type >UCP215

¥15,893

SKU: r220578884fb6 Category:

Description

Contents: 1 piece
Shaft diameter (mm): 75
Basic dynamic load rating (kN): 66

Dimension A (mm): 74
Dimension B (mm): 77.8
Dimension H (mm): 82.6
Dimension H1 (mm): 28
Dimension H2 (mm): 163
Dimension J (mm): 217
Dimension L (mm): 275
Dimension L1 (mm): 80
Dimension N (mm): 25
Dimension N1 (mm): 28
Dimension S (mm): 33.3
Shaft diameter (mm): 75
Shape: Pillow block unit
Grease nipple: None
Load type: Light load
Cover: No cover
Shaft hole type: Cylindrical hole type (with set screw)
Weight (kg): 7.4
Basic static load rating (kN): 49.5
Basic dynamic load rating (kN): 66
Bearing designation: UC215D1
Mounting bolt designation: M20
Bearing housing designation: P215

This is a representative type of bearing unit that corresponds to a combination of the traditionally widely used plummer block and self-aligning bearing, which can be easily mounted onto the shaft by simply tightening the set screw with a ball, and is most commonly used in transmission devices and general machinery.
