Description
Description: Quantity: 1 piece
Operation Method: Reversible (with Perfect Lock)
Presence of Case: Without Case Cover
Coil Rated Voltage (V): AC100
Model Number: SC-03HRM Coil AC100V 1B * 2
Rated Continuous Current (A): 20
Rated Operating Voltage (V): AC200
Auxiliary Contacts: 1b * 2
Frame: Type 03
Coil Rated Voltage (V): AC100
Release Voltage (V): 50Hz: 70-98, 60Hz: 80-110
International Standards Compliance: IEC, EN, VDE, BS, UL, CSA Certified
Type: SC-03HRM
Compatible Thermal Relay: TR-0N
Compatible Rail Width (mm): 35
Electrical Durability: 2 million cycles (AC-3), 30,000 cycles (AC-4), 500,000 cycles (AC-1)
Mechanical Durability: 10 million cycles
Electromagnet Capacity (VA)/At Activation 200V 50Hz: 90/200-220V 60Hz: 95
Electromagnet Capacity (VA)/At Retention 200V 50Hz: 9, 200-220V 60Hz: 9
Operation Time (ms): (Coil ON 闂?Main Contact ON) 9-20, (Coil OFF 闂?Main Contact OFF): 5-16
Closed Circuit Voltage (V): 50Hz: 53-63, 60Hz: 58-68
Accessories: Includes 2 Heat Element Thermal Relays
Length (mm): 81
Width (mm): 80
Thickness (mm): 43
Weight (kg): 0.32
Type: Electromagnetic Contactor
Protection Structure: Without Case Cover
Contact Configuration: [Auxiliary] High Capacity Auxiliary Contacts: (Single Contact): Included
Rated Insulation Voltage (V): 690
Operation Method: Reversible (with Perfect Lock)
Rated Frequency (Hz): 50/60
Reset Method: Manual
Mounting Screw: 2-M4
Rated Impulse Withstand Voltage (kV): 6
Loss (W): 200V 50Hz: 2.7, 200-220V: 2.8
Coil Voltage (V): AC100
Opening/Closing Frequency (times/hour): 1800 (AC-3), 600 (AC-4)
Presence of Case: Without Case Cover
Rated Capacity (kW) Three-Phase Squirrel Cage Motor (AC-3): (200-240V) 2.2, (380-440V) 2.7
Rated Capacity (kW) Single-Phase Motor (AC-3): 0.4 (100-120)
Rated Capacity (kW) Inch Plugging (AC-4): (200-240): 1.5, (380-440): 2.2
