NSK (Nippon Seiko Kabushiki Kaisha) Pillow Block Unit, Oil – free type >UCP210

¥4,960

SKU: r220528244bba Category:

Description

Capacity: 1 piece
Axis diameter (mm): 50
Basic dynamic load rating (kN): 35

Dimension A (mm): 60
Dimension B (mm): 51.6
Dimension H (mm): 57.2
Dimension H1 (mm): 21
Dimension H2 (mm): 114
Dimension J (mm): 159
Dimension L (mm): 206
Dimension L1 (mm): 65
Dimension N (mm): 20
Dimension N1 (mm): 23
Dimension S (mm): 19
Axis diameter (mm): 50
Shape: Pillow block unit
Grease nipple: No grease nipple
Load type: For light load
Cover: No cover
Axis hole type: Cylindrical hole type (with set screw)
Weight (kg): 2.6
Basic static load rating (kN): 23.2
Basic dynamic load rating (kN): 35
Bearing designation: UC210D1
Mounting bolt designation: M16
Bearing housing designation: P210

This is a typical type of bearing unit, equivalent to the combination of the widely used plummer block and self-aligning bearing. It can be easily mounted onto the shaft by simply tightening the set screw with the ball, and is most commonly used in drive equipment and general machinery.
