Description
Color: Gasket: Black
Dimension W (mm): 280
Dimension D (mm): 280
Dimension H (mm): 130.5
Material: Mounting base screw: Steel
Specification: nut: Included
Type: T Type
Operating temperature range (Celsius degrees): -10 to 60
Dimension A (mm): 238 (bottom mounting hole)
Surface treatment: latch: Unprocessed, mounting base screw: Tri-valued chromate
Protection level: IP65
Dimension c (mm): 238 (bottom mounting hole)
Material (cover): Polycarbonate
Flammability: UL94HB
Material (gasket): Polyurethane
Material (body): ABS resin
Color (cover): Transparent
Compatible body color: White Gray
RoHS Directive (10 substances compliant): Compliant
Features: Waterproof Dustproof Open-Close
Self weight (g): 1200
Effective width (mm): 254 (internal)
Effective depth (mm): 254 (internal)
Effective height (mm): 113.6 (internal)
Material (latch): Stainless Steel
