Description
Color: Gasket: Black
Dimension W (mm): 160
Dimension D (mm): 260
Dimension H (mm): 130
Material: Mounting base screw: Iron
Specification: Nut: None
Type: G Type
Operating temperature range (Celsius degrees): -10 to 60
Dimension A (mm): 120 (Bottom mounting hole)
Surface treatment: Latch: Untreated, Mounting base screw: Trivalent chromate
Protection rating: IP65
Dimension c (mm): 220 (Bottom mounting hole)
Material (Cover): ABS resin
Flame resistance: UL94HB
Material (Gasket): Polyurethane
Material (Body): ABS resin
Color (Cover): White Gray
Compatible body color: White Gray
RoHS directive (10 substances compliance): Compliant
Characteristics: Waterproof Dustproof Open-Close
Weight (g): 673
Effective dimension (Width) (mm): 134 (Internal)
Effective dimension (Depth) (mm): 234 (Internal)
Effective dimension (Height) (mm): 116.6 (Internal)
Material (Latch): Stainless steel
