Description
Dimension a (mm): 194
Dimension b (mm): 354
Dimension d (mm): 243
Dimension e (mm): 339
Dimension f (mm): –
Length C (mm): 400
Type: Slide type
Travel distance (mm): 300
Rail length (mm): 400
Number of steps: 2
Material: (Rail) Steel
Surface treatment: (Rail) Zinc plating
Set contents: 1 piece for each side
Material: Steel
Color: Uni-black
Weight (1 set) (kg): 0.755
Finish: Zinc plating
Mounting screws (flat head wood screws) 2.7 to 3.1
Static load capacity (kg): 25
The inner rail is removable.
When the drawer is completely closed, the stopper engages.
Thanks to the cushioning effect of the outer mounting part, smooth sliding is achieved even with slight deformation of the cabinet.
